Zoom L12 LiveTrak Mixer / Recorder

Overview
The LiveTrak L-12 is a powerful digital console that offers 12 discrete channels (8 mono and 2 stereo) with XLR or 1/4-inch connectivity, making it the only board you need for mixing, recording, monitoring, playback, and remixing. It also features 14-track simultaneous recording, 12-track playback, and a 14-in/4-out USB audio interface for easy connectivity.

With 5 powered headphone outputs, customizable mixes, built-in compression control, and 16 built-in delay and reverb effects, the LiveTrak L-12 provides effortless live mixing and recording. It also has a built-in slate mic, metronome, and automatic recording starting/stopping capabilities, making it a versatile tool for any live performance. Plus, with its Class-D power amplifier and 16 onboard effects, the L-12 delivers high-quality sound in any environment.

Included in box
1x L12 LiveTrak Mix
1x AC adapter (AD-19)
1x USB 2.0 cable
1x Quick Guide

About the Zoom L12 LiveTrak Mixer / Recorder
The Livetrak -The board that does it all

Mix, Record, Monitor, Playback, and Remix

The LiveTrak L-12 is the only digital console that lets you mix your live performance and record up to 12 discrete channels, all while providing five individual custom headphone mixes. Now you can mix, record, and monitor with a single piece of gear.

Effortless Live Mixing

LiveTrak’s 12 discrete channels (eight mono plus two stereo) have a 3-band mid-parametric EQ and 16 built-in send effects. Its eight mono channels also have a dedicated compressor. With all these controls plus its 12-segment LED metering, the L-12 offers just what you need for intuitive mixing.

Record Everything, Remix Anywhere

The L-12 lets you record 12 tracks up to 24-bit/96kHz WAV audio to an SD card while simultaneously mixing your live show. Mix and overdub your finished project onLiveTrak, or transfer the discrete tracks to your favorite DAW for further mixing and editing.

Five Custom Monitoring Mixes

LiveTrak provides five headphone monitor outputs which can be individually mixed, allowing each performer a feed that works best for them. With its Class-D power amplifier, the L-12 delivers volume that stands up in any live environment without the need for a separate headphone monitoring setup.

The Channel Strip

All 12 inputs include a track fader and mute button. The eight mono inputs also include single-knob compression and gain control. Record or playback individual channels with the “Rec/Play” button. Use the “Select” button to apply Channel Strip settings (EQ and panning controls, and “EFX Return” settings) to the selected channel.

Easy EQ Control

The L-12 provides a smooth 3-band mid-parametric EQ and a low cut function for each input channel.

Plenty of Inputs

The L-12’s combo inputs support XLR or 1/4-inch connections. Channels 1 and 2 offer Hi-Z inputs for connecting an electric guitar or bass. Channels 9 through 12 have TS line connectivity for keyboards and other audio devices, as well as RCA inputs.

Navigation and Display

LiveTrak’s bright, backlit LCD screen and encoder knob let you access an intuitive menu system to create new projects, recall previous projects, and customize your recorder settings.

USB Connectivity for Your DAW

LiveTrak is also a 14-in/4-out USB audio interface with flexible routing options, offering unlimited possibilities.

16 Onboard Effects

The L-12 offers 16 built-in effects, all with fully adjustable parameters. Choose from delay and reverb effects and send them to any channel.

Custom Scene Settings

Save up to nine different scenes and recall your custom settings automatically. Each scene saves fader position, EQ settings, pan, mute, and more. The “Fader Mode” buttons allow you to design custom mixes for both the Master and monitor outs.

Slate Mic and Metronome

Use the built-in slate mic to record comments or talk-back, and program the metronome to your desired tempo.

Convenient Auto Recording

Record automatically by adjusting the L-12’s customizable audio input commands. Set it to start when the master fader detects a certain dB level, or use a guitar chord or snare hit to start the track. You can capture data up to two seconds before recording starts, in case a performance begins ahead of time.

Our Best Mic Preamps Yet

At -128dBu EIN (super-low-noise floor) with +60dB maximum input gain, LiveTrak is equipped with the quietest and most advanced preamps we’ve ever made. Just wait until you hear how incredible it sounds.

High-Definition Sample Rates

The L-12 supports sample rates up to 96 kHz when recording to an SD card, allowing you to record in high definition. In Audio Interface mode, the L-12 can record up to 48 kHz to a computer and an SD card simultaneously.

Versatile Operation Modes

The L-12 is equipped with several operationmodes. Audio Interface mode lets you route inputs and outputs to any DAW.

With USB Host mode, transfer projects and audio files to a connected USB flash drive. In Card Reader mode, the L-12 acts as an SD card reader, allowing you to transfer audio files to and from your computer. With Class Compliant Mode, you can connect to a supported iOS device.

NUMBER OF INPUT AND OUTPUT CHANNELS
Inputs Mono (MIC/LINE): 8
Stereo (LINE): 2
Outputs MASTER OUT: 1
MONITOR OUT: 5
INPUTS
Mono (MIC/LINE) Type: XLR/TRS combo jacks
(XLR: 2 HOT, TRS: TIP HOT)
Input gain:
PAD OFF: +16 – +60 dB
PAD ON: −10 – +34 dB
Hi-Z ON: +6 – +50 dB
Input impedance:
XLR: 3 kΩ
TRS: 10kΩ/1 MΩ (when Hi-Z ON)
Maximum input level:
PAD OFF: 0 dBu (at 0 dBFS)
PAD ON: +26 dBu (at dBFS)
Phantom Power
+48 V
Stereo (LINE) Type: TRS phone/RCA pin (unbalanced) jacks
Maximum input level +10 dBu
OUTPUTS
MASTER OUT Type: XLR jacks (balanced)
Maximum output level: +14.5 dBu
Output impedance: 100 Ω
MONITOR OUT A (TRS) Type: TRS phone jacks (balanced)
Maximum output Level: +14.5 dBu
Output impedance: 100 Ω
MONITOR OUT A-E (PHONES) Type: Standard Stereo phone jacks
Maximum output level: 42 mW + 42 mW at 60 Ω
Output impedance: 100 Ω
BUSES
MASTER 1
MONITOR 5
SEND EFX 1
CHANNEL STRIP
COMP
LOW CUT 75 Hz, 12 dB/OCT
EQ HIGH: 10 kHz, ± 15 dB, shelving
MID: 100 Hz-8 kHz, ±15 dB, peaking
LOW: 100 Hz, ± 15 dB, shelving
LEVEL METERS
Level segments 12
SEND EFFECTS
Effects 16 types:
Hall 1 & 2 (reverb)
Room 1 & 2(reverb)
Plate (reverb)
Church (reverb)
DrumAmb (reverb)
GateRev (reverb)
Spring (reverb)
Delay (delay)
Analog (delay)
P-P Dly (delay)
Vocal 1-4 (delay + reverb)
RECORDER Maximum simultaneous recording tracks:
14 at 44.1/48 kHz (12 channel + stereo mix)
12 at 96 kHz
Maximum simultaneous playback tracks 12
Recording format WAV 44.1/48/96 kHz, 16/24-bit, mono/stereo WAV format
Recording media 16 MB-2 GB SD cards, 4 GB-32 GB SDHC cards, 64 GB-512 GB SDXC cards
AUDIO INTERFACE
44.1/48 kHz Recording: 14 channels
Playback: 4 channels
Bit depth 24-bit
Interface USB 2.0
SYSTEM REQUIREMENTS
Windows: OS： Windows® 7 SP1 or later / 8.1 / 10
(32bit/64bit)
CPU: Intel® Core i3 or faster*
USB: USB 3.0/USB 2.0**
* Operation is not guaranteed with CPUs from Atom, Celeron or Pentium series or CPUs made by AMD.
** Only USB host controllers with Intel Chipsets are supported. Operation is not guaranteed when used with USB hubs or expansion cards.
Mac OS： Mac® OS X 10.10 / 10.11 / 10.12
CPU: Intel® Core i3 or faster
USB: USB 3.0/USB 2.0*
* Operation is not guaranteed when used with USB hubs or expansion cards.
iPhone/iPad OS： iOS 8 / 9 / 10
* Apple Lightning-to-USB Camera Adapter required.
CARD READER
Class Mass storage
USB 2.0 High Speed
USB HOST
Class USB 2.0 High Speed
SAMPLING RATE
Sampling rate 44.1/48/96 kHz
FREQUENCY CHARACTERISTICS
44.1 kHz -1.0 dB: 20 Hz – 20 kHz
96 kHz -3.0 dB: 20 Hz – 40 kHz
EQUIVALENT INPUT NOISE
Actual measurements -128 dB EIN (IHF-A) with +60 dB/150 Ω input
Display LCD with backlight (128×64 resolution)
Power supply ZOOM AD-19 AC adapter (DC12 V/2 A)
Power consumption 17W maximum
External dimensions 445 mm (W) x 282 mm (D) x 70.5 mm (H)
17.5” (W) x 11.1” (D) x 2.78” (H)
Weight (main unit only)
2.53 kg / 5.58 lbs

12 discrete channels (8 mono plus 2 stereo) with XLR or 1/4-inch connectivity
14-track simultaneous recording, 12-track playback
14-in/4-out USB audio interface connectivity
5 powered headphone outputs, each with a customizable and saveable mix
Add backing/click tracks from your computer to your live mix and recording
RCA and TRS line inputs
48V phantom power (channels 1-4 and 5-8)
Hi-Z connectivity (channels 1 and 2)
26 dB pad (channels 3-8)
Built-in compression control (Channels 1-8)
Digital level meters -48 dB to -0 dB
Master mute button
Low-cut control
Stereo panning
Master and Monitor Outputs A-E
Scene saving function, up to 9 scenes saved at a time
16 built-in delay and reverb effects with adjustable parameters
Built-in slate mic
Class-compliant mode (for iOS compatibility)
SD card input
Built-in metronome
Automatic recording starting/stopping capability
Project protection
Import/export projects with USB 2.0 host port
Latency adjustment for A-to-D conversion
Compatible functions for ZOOM FS01 footswitch
